Overall Dimension:
Bale Opener: 5200*1550*2350mm Customizable
Fiber Opener: 2500*1500*1100mm Customizable
Storage Box: 1700*1800*3100mm
Weighing machine: 4100*2850*5100mm
Negative pressure box: 1650*1250*1650mm
Power: 60-75kw
Voltage: 380V-50HZ-3Phase
Weight: 4500KG
Function: The fibers are automatically and evenly fed into the cotton opening machine through the feeding machine After loosening, it is transported to the material box and weighed by the weighing system to a set weight. Then, it is filled into the target product through a negative pressure box.
One loading weight: approximately 300 kilograms
Fiber production capacity: 400-500 kg/hour
Filling capacity: 300-350 pieces/hour. The standard error for 700g pillow core is around 2%
Target products: Sofa cushions, pillow cores
Features: One click start with automatic feeding Auto fill The product is smooth and full The surface is clean and tidy without sticking fibers Easy operation by one person on the entire machine
